Styryl 9
General Information
| Dye Name | Styryl 9 |
| Synonyme | 2-[[3-[2-[4-(Dimethylamino)phenyl]ethenyl]-5,5-dimethyl-2-cyclohexen-1-ylidene]methyl]-3-ethylbenzothiazolium perchlorate |
| Sirah Order-Code | SDL-690 |
| Chemical Formula | C28H33N2S•ClO4 |
| CAS No. | 105893-63-8 |
| Appearance | green crystalline powder |
| Further Information | see Datasheet provided by Exciton |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 815 nm |
| Tuning Range | 791 - 839 nm |
| Efficiency | 11 % |
| Concentration | 0.13 g/l |
| Solvent | DMSO |
| Peak | 839 nm |
| Tuning Range | 814 - 862 nm |
| Efficiency | 11 % |
| Concentration | 0.13 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 815 nm |
| Tuning Range | 791 - 839 nm |
| Efficiency | 10 % |
| Conc. Resonator | 0.195 g/l |
| Conc. Amplifier | 0.13 g/l |
| Solvent | DMSO |
| Peak | 839 nm |
| Tuning Range | 814 - 862 nm |
| Efficiency | 10 % |
| Conc. Resonator | 0.195 g/l |
| Conc. Amplifier | 0.13 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
