Styryl 11
General Information
| Dye Name | Styryl 11 |
| Synonyme | 4-(4-(4-(Dimethylamino)phenyl)-1,3-butadienyl)-1- ethylquinolinperchlorat |
| Sirah Order-Code | SDL-680 |
| Chemical Formula | C23H25N2•ClO4 |
| CAS No. | 92479-59-9 |
| Appearance | dark maroon crystals |
| Further Information | see Datasheet provided by Exciton |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 785 nm |
| Tuning Range | 758 - 826 nm |
| Efficiency | 13 % |
| Concentration | 0.14 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 785 nm |
| Tuning Range | 758 - 826 nm |
| Efficiency | 12 % |
| Conc. Resonator | 0.21 g/l |
| Conc. Amplifier | 0.14 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
