Stilbene 3
General Information
| Dye Name | Stilbene 3 |
| Synonyme | Stilbene 420 |
| Sirah Order-Code | SDL-300 |
| Chemical Formula | C28H22(NaO3S)2 |
| CAS No. | 38775-22-3 |
| Appearance | yellow powder |
| Further Information | see Datasheet provided by Exciton |
Usage with CW Single-Mode Lasers
| Solvent | Ethylene glycol |
| Peak | 455 nm |
| Tuning Range | 425 - 465 nm |
| Efficiency | |
| Concentration | 1.25 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol + H2O |
| Peak | 425 nm |
| Tuning Range | 419 - 434 nm |
| Efficiency | 16 % |
| Concentration | 0.22 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol + H2O |
| Peak | 425 nm |
| Tuning Range | 419 - 434 nm |
| Efficiency | 15 % |
| Conc. Resonator | 0.33 g/l |
| Conc. Amplifier | 0.22 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
