Rhodamine 6G
General Information
| Dye Name | Rhodamine 6G (Perchlorate) |
| Synonyme | Rhodamine 590 (Perchlorate) |
| Sirah Order-Code | SDL-470 |
| Chemical Formula | C28H31N2O3•ClO4 |
| CAS No. | 13161-28-9 |
| Appearance | red to violet |
| Further Information | see Datasheet provided by Exciton |
Usage with CW Single-Mode Lasers
| Solvent | Ethylene Glycol |
| Peak | 576 nm |
| Tuning Range | 565 - 610 nm |
| Efficiency | |
| Concentration | 0.75 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol |
| Peak | 574 nm |
| Tuning Range | 563 - 597 nm |
| Efficiency | 16 % |
| Concentration | 0.40 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 566 nm |
| Tuning Range | 559 - 576 nm |
| Efficiency | 30 % |
| Concentration | 0.09 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol |
| Peak | 574 nm |
| Tuning Range | 563 - 597 nm |
| Efficiency | 14 % |
| Conc. Resonator | 0.60 g/l |
| Conc. Amplifier | 0.40 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 566 nm |
| Tuning Range | 559 - 576 nm |
| Efficiency | 28 % |
| Conc. Resonator | 0.135 g/l |
| Conc. Amplifier | 0.09 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
