Pyrromethene 597
General Information
| Dye Name | Pyrromethene 597 |
| Synonyme | [[(4-Tert-butyl-3,5-dimethyl-1H-pyrrol-2-yl)(4-tert-butyl-3,5- dimethyl-2H-pyrrol-2-ylidene)methyl]methan](difluoroboran) |
| Sirah Order-Code | SDL-450 |
| Chemical Formula | C20H33BF2N2 |
| CAS No. | 137829-79-9 |
| Appearance | red-orange solid |
| Further Information | see Datasheet provided by Exciton |
Usage with High-Energy Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol |
| Peak | 585 nm |
| Tuning Range | 571 - 612 nm |
| Efficiency | 13 % |
| Concentration | 0.32 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 582 nm |
| Tuning Range | 566 - 611 nm |
| Efficiency | 29 % |
| Concentration | 0.16 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol |
| Peak | 585 nm |
| Tuning Range | 571 - 612 nm |
| Efficiency | 12 % |
| Conc. Resonator | 0.48 g/l |
| Conc. Amplifier | 0.32 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 582 nm |
| Tuning Range | 566 - 611 nm |
| Efficiency | 28 % |
| Conc. Resonator | 0.24 g/l |
| Conc. Amplifier | 0.16 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
