Mix. Rhodamine B / 101
General Information
| Dye Name | Rhodamine B (Chloride) |
| Synonyme | Rhodamine 610 (Chloride) |
| Sirah Order-Code | SDL-500 |
| Chemical Formula | C28H31ClN2O3 |
| CAS No. | 81-88-9 |
| Appearance | green crystals or reddish-violet powder |
| Further Information | see Datasheet provided by Exciton |
| Dye Name | Rhodamine 101 (Perchlorate) |
| Synonyme | Rhodamine 640 (Perchlorate) |
| Sirah Order-Code | SDL-530 |
| Chemical Formula | C32H31N2O3•ClO4 |
| CAS No. | 72102-91-1 |
| Appearance | dark green crystals with bronze sheen |
| Further Information | see Datasheet provided by Exciton |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 615 nm |
| Tuning Range | 598 - 636 nm |
| Efficiency | 27 % |
| Concentration | 0.17 + 0.04 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 615 nm |
| Tuning Range | 598 - 636 nm |
| Efficiency | 26 % |
| Conc. Resonator | 0.255 + 0.06 g/l |
| Conc. Amplifier | 0.17 + 0.04 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
