Fluorescein 27
General Information
| Dye Name | Fluorescein 27 |
| Synonyme | 2',7'-Dichlorofluorescein |
| Sirah Order-Code | SDL-400 |
| Chemical Formula | C20H10Cl2O5 |
| CAS No. | 76-54-0 |
| Appearance | pale yellow crystals |
| Further Information | see Datasheet provided by Exciton |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol + H2O |
| Peak | 550 nm |
| Tuning Range | 541 - 571 nm |
| Efficiency | 28 % |
| Concentration | 0.40 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol + H2O |
| Peak | 550 nm |
| Tuning Range | 541 - 571 nm |
| Efficiency | 27 % |
| Conc. Resonator | 0.6 g/l |
| Conc. Amplifier | 0.4 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
