DCM
General Information
| Dye Name | DCM |
| Synonyme | 4-(Dicyanomethylene)-2-methyl-6-(4-dimethylaminostyryl)- 4H-pyran |
| Sirah Order-Code | SDL-550 |
| Chemical Formula | C19H17N3O |
| CAS No. | 51325-91-8 |
| Appearance | red or orange-red crystals or powder |
| Further Information | see Datasheet provided by Exciton |
Usage with CW Single-Mode Lasers
| Solvent | Phenoxyethanol |
| Peak | 635 nm |
| Tuning Range | 610 - 665 nm |
| Efficiency | |
| Concentration | 1.0 g/l |
| Solvent | Phenoxyethanol : Ethylene glycol (1:1) |
| Peak | 660 nm |
| Tuning Range | 645 - 690 nm |
| Efficiency | |
| Concentration | 1.0 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 355 nm
| Solvent | Ethanol |
| Peak | 640 nm |
| Tuning Range | 605 - 665 nm |
| Efficiency | 14 % |
| Concentration | 0.30 g/l |
Usage with High-Energy Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 627 nm |
| Tuning Range | 602 - 660 nm |
| Efficiency | 28 % |
| Concentration | 0.3 g/l |
| Solvent | DMSO |
| Peak | 651 nm |
| Tuning Range | 626 - 685 nm |
| Efficiency | 28 % |
| Concentration | 0.3 g/l |
Usage with High-Repetition-Rate Pulsed Lasers Pumped at 532 nm
| Solvent | Ethanol |
| Peak | 627 nm |
| Tuning Range | 602 - 660 nm |
| Efficiency | 27 % |
| Conc. Resonator | 0.45 g/l |
| Conc. Amplifier | 0.30 g/l |
| Solvent | DMSO |
| Peak | 651 nm |
| Tuning Range | 626 - 685 nm |
| Efficiency | 27 % |
| Conc. Resonator | 0.45 g/l |
| Conc. Amplifier | 0.30 g/l |
Solvent: The solvent influences the peak wavelength of the dye.
Peak: Output maximum of tuning curve.
Effciency: Laser output at the maximum of tuning range, relative to pump laser output. Effciencies may change depending on configuration or pump power level.
Concentration: Amount of dye, in grams, for 1 liter stock solution. Higher concentrations cause a shift of tuning curves to the red, while lower concentrations may result in a blue shift.
